Manual freewheel hub AVM 457HP - Suzuki
Set of 2 manual freewheel hubs AVM 457HP serve as detachable freewheeling hubs for the front wheels on selected 4x4 and off-road vehicles. When manually engaged, they connect the wheel hub with the front axle half-shaft, so that when four-wheel drive is engaged the driving force can also be transmitted to the front wheels. When disengaged, the front wheels in 4x2 driving rotate freely without unnecessarily turning parts of the front drive, which helps reduce mechanical resistance and wear. The freewheels complement the 4x4 drive controls and do not replace activating the vehicle's 4x4 system. The HP (High Performance) series is designed for heavy load and demanding off-road use; the robust steel construction with epoxy coating is prepared for extreme outdoor conditions, precision-manufactured internal components emphasize the durable construction, and the set can also be used with wheels larger than 33 inches.
Suitable for models:SuzukiTechnical specifications:- Number of splines on the half-shaft: 26
- Number of bolts: 6
- Thread of mounting bolts: M8x1.25
- Pitch circle diameter (PCD): 90 mm
- AVM service kit: 4457HP
- Package contents: 2 pcs
- Package dimensions: 11 x 21.5 x 9 cm
- Package weight: 5 kg
